print this pageIntroduction into Stability
In the following table study material can be downloaded such as sheets and assignments regarding Stability of Equilibirum as part of the Strucutral Mechanics Bridging programme to TU Delft Civil Engineering master. |
Mechanica: Stabiliteit van het Evenwicht, Coenraad Hartsuijker en Hans Welleman, Boom Uitgevers,
2023, ISBN 978-90-2444-603-2.(in Dutch) Students should order the book from the bookshop. |
Press the symbol
for downloading. |  | description |
| Dutch Book | ||
|
Summary Book (in Dutch) | |
|
Summary Card Book (in Dutch) | |
|
Available answers from problems chpt 1-4 (in Dutch) | |
| Chapter 7, 12 and 13 are not part of the exam. | ||
| CHAPTER 1,2,3 part 1, lectures 1 | ||
| slides part 1, intro and systems with 1 dof | |
| CHAPTER 1,2,3 assignments | ||
| Read chapter 1 and 2 and study the examples from the book carefully, start with the assignments and finish these at the end of the week. | ||
| CHAPTER 4 part 2, lecture 2 | ||
| slides part 2, systems with 2 and infinite number dofs | |
|
| Additional notes on example 3 of chpt 4 (in Dutch) |
| CHAPTER 4 assignments | ||
| Read chapter 3 and 4 study the examples from the book carefully. Example 3 and 4 from chapter 4 is reading. Start with the assignments and finish these at the end of the week. | ||
| CHAPTER 5,6 part 3, lectures 3, 4 and 5 | ||
| slides part 3, flexural buckling, Eulerian approach | |
|
| Note, equivalent rotational spring stiffness |
| python script to find buckling load, basic type 1 | |
| python script to find buckling load, basic type 2 | |
| python script to find buckling load, basic type 3 | |
| python script to find buckling load, basic type 4 | |
| python script to find buckling load, basic type 5 | |
|
python script to find numerical buckling load, example with different EI from slides | |
|
python script to find numerical buckling load, example with two forces from slides | |
|
| Summary of formulas flexural buckling |
| CHAPTER 5,6 assignments | ||
| Read chapter 5 and 6 and study all the examples from the book carefully. Paragraph 6.1.2 and 6.1.3 are reading only. Start with the assignments and finish these at the end of the week. | ||
|
| python script to find numerical buckling load, cantilver beam with spring |
| CHAPTER 8,10,11 part 4, lectures 6 and 7 | ||
| slides part 4, Coupled systems and effective load on stability element | |
| slides part 5, Post-buckling and second order effect | |
| slides part 6, Rayleigh's Quotient | |
| CHPATER 8,10,11 assignments | ||
| Read chapter 8 and study some examples from the book carefully. Start with the assignments and finish these at the end of the week. | ||
